UV Curer KW-4AC,110V
For those that want to quickly UV cure photosensitive coatings and thin films, SPI Supplies offers a compact and easy to use UV Curer. It is equipped with two UV light sources with wavelengths of 365 nm and 245 nm. The system coats substrates up to 6 in diameter while rotating at 6 rpm to ensure uniform curing. The built-in interlock door prevents the exposure of UV radiation and provides a safe operation. In conjunction with the KW-4A spin coater, the system can be used to make various coatings and thin films via the photochemical process.Specifications:
- UV Wavelength: 365nm/ 254nm
- Power output: 4x4 watts bulbs
- Table Diameter: 4" diameter
- Maximum Sample size: 6" diameter
- Turntable Rotary Speed: 5~6 rpm
- Dimension: 5.8"(W), 9.5"(D), 6.3"(H)
- Compliance: CE compliant.
UV curing is a photochemical process by which monomers undergo polymerization or cross inking (curing) upon exposure to ultraviolet radiation. A specially formulated monomer will polymerize when exposed to ultraviolet radiation. This UV "curable" monomer includes a sensitizer which absorbs UV energy and initiates a polymerizing reaction in the monomer.
