Quantifoil S7/2 Micromachined Square Mesh Holey Carbon Grids,  Mesh Gold, Slide a Grid Box
Quantifoil S7/2 Micromachined Square Mesh Holey Carbon Grids, Mesh Gold, Slide a Grid Box
Click to enlarge

Quantifoil S7/2 Micromachined Square Mesh Holey Carbon Grids, Mesh Gold, Slide a Grid Box

Size Options for Quantifoil S7/2 Micromachined Square Mesh Holey Carbon Grids, Mesh Gold, Slide a Grid Box
Size 200 Mesh
Item Number 4620G-XA
Availability In Stock
Price  $851.07
Size 300 Mesh
Item Number 4630G-XA
Availability Contact for Availability
Price  $851.07
Size 400 Mesh
Item Number 4640G-XA
Availability Contact for Availability
Price  $851.07
Size 100 x 400 Mesh
Item Number 4650G-XA
Availability Contact for Availability
Price  $879.80

Quantifoil with square holes, or which is in the form of a square mesh, with relatively thin "bars" can be used in conjunction with TEM work, where the carbon film being used is too thin to span the distance between grid bars or to support sections from which EDS is being done. The square hole film is also useful for particles that are larger than one of the 7x7 µm holes. Quantifoil S7/2 represents the optimum geometry when ones requires not only good mechanical stability on the one hand, but also maximum open area.

Other square mesh parameters:
Square hole size: ~ 7 µm
Bar width: ~ 2 µm
Repeat Distance: 9 µm

The Quantifoil holey films are available on "standard, stock" grid mesh, namely 200, 300, 400, and 100x400 mesh, in Cu, Ni, Au and Rh plated Cu. Other grid meshes and other grid constructions are possible, of course, but on special order and for a higher price.

The square mesh film is also available on the
